Type: Vanadium Oxide Non-cooling Focal Plane Detector

Image resolution ratio:256×192,384×288,640×512

Pixel size: 12μm

NETD:≦40MK@25℃

Response band:8~14μm

Lenses(optional): 4mm,4.5mm，9mm,15mm,19mm,25mm,35mm，50mm,100mm

Ethernet type: 100Mbps

Networking protocol: IPV4, HTTP, FTP, RTSP, RTCP, RTP, TCP, UDP

Access standards: ONVIF, RTSP, 28181

Digital video:H264/H.265

Image processing: Non-uniformity correction,intelligent gain control,digital detail mixing enhancement,3D noise reduction

Palette: Support black heat,white heat,iron red,rainbow and other 10 palettes/ customizable Alarminput/output :1in/1out

 Scope of power supply :DC/12V

Typical power consumption: 1.6W

 Product size (excluding lens): 42mm*42mm*51.5mm

Weight (excluding accessories) :156.5g
