Ultra-compact FASST64017M12 Thermal Camera! 640×512 resolution, 12μm pixel, 18 color palettes, multi-video/serial ports, tiny footprint & under 20g. Built for seamless embedded thermal solutions.

FASST64017M12 ,ThermalImagingCamera ,InfraredCamera ,640x512Thermal ,12μmPixel ,MiniThermalModule ,UVC ,CVBS ,MIPI ,EmbeddedThermal , LightweightThermal ,DroneThermal

Product model: FASST64017M12

Detector type: Uncooled vanadium oxide focal plane detector

Resolution: 640 × 512

Pixel pitch: 12 μm

Frame rate: Supports 25/30/50, default 50

Response wavelength range: 8 μm - 14 μm

Lens focal length (mm): 9.1/13/19/25

Aperture: F1.0/F1.2 Field of view

9.1mm --- 48.3 × 38.7

13mm --- 33.9 × 27.1

19mm --- 23.0 × 18.4

25mm --- 17.3 × 14.0

Pseudo-color: Supports 18 types of pseudo-color adjustments such as white heat, black heat, rainbow, iron red, etc.

Image interface: UVC (USB2.0) / CVBS / MIPI / BT656

Serial communication: USB / UART

Power supply range: 4.5 - 5.5V (supports 5 - 24V for expansion board)

Typical power consumption @ 25℃: < 0.7W

Operating temperature: -40℃ - +70℃

Storage temperature: -40℃ - +80℃

Operating humidity: 5% - 95%, no condensation

Product size: 17.3mm × 17.3mm × 24.3mm (including 9.1mm lens)

Net weight: < 20g
