FW2 The entire series features high refresh rates of 50/60Hz

Standard feature is Shutterless without gears

Compatible with various lenses and multiple interfaces

Application fields:

Agriculture and animal husbandry

Industrial applications

Gas detection

Medical diagnosis

Preventive maintenance

Steel and metallurgy

Petroleum and chemical industry

Power maintenance

Detector Type: Vanadium oxide uncooled infrared focal plane detector

Resolution: 256×192/384×288/640×512

Detector frame rate: 25/50Hz/ 30/60Hz

Response band: 8 - 14 μm

Noise Equivalent Temperature Difference (NETD): ≤ 40 mK @ 25℃, F#1.0, 25Hz

Non-uniformity correction: shutter correction / algorithm correction without blocking

Brightness/contrast adjustment: 0 ~100 steps selectable

Polarity/Pseudo-color: white heat / black heat / supports various pseudo-colors

Electronic zoom: 1.0 ~ 8.0× continuous zoom (step size 0.1)

Image mirroring: up/down / left/right / diagonal

Analog video: PAL format / NTSC format

Digital video: DVP / BT656 / USB2.0 / MIPI

Communication interface: UART / I²C / USB2.0

Power supply input: 5V

Typical power consumption of USB output @ 25℃: < 0.35W / < 0.42W / < 0.7W

Size (without lens): 21×21×10.3mm

Weight (without lens): < 7g/< 7g/< 8.6g

Operating temperature: Imaging -40℃ to 80℃, Temperature measurement: -20℃ to 70℃

Storage temperature: -50℃ ~ +85℃

Humidity: 5% - 95%, no condensation

Vibration: 6.06g, random vibration, all axes

Impact: 80g @ 4ms, peak sawtooth wave, 3-axis 6 directions
